Main Dimensions & Performance Data
| d | 95.00 mm | Bore diameter |
| D | 200.00 mm | Outside diameter |
| B | 67.00 mm | Width |
| Cr | 540,000.00 N | Basic dynamic load rating, radial |
| C0r | 580,000.00 N | Basic static load rating, radial |
| Cur | 101,000.00 N | Fatigue load limit, radial |
| nG | 6,100.00 1/min | Limiting speed |
| nϑr | 2,800.00 1/min | Reference speed |
| ≈m | 10.30 kg | Weight |
Mounting dimensions
| da min | 109.00 mm | Minimum diameter shaft shoulder |
| da max | 119.00 mm | Maximum diameter of shaft shoulder |
| Da max | 186.00 mm | Maximum diameter of housing shoulder |
| dc min | 134.00 mm | Minimum shaft shoulder |
| ra max | 2.50 mm | Maximum recess radius |
Dimensions
| rmin | 3.00 mm | Minimum chamfer dimension |
| r1 min | 3.00 mm | Minimum chamfer dimension |
| s | 5.60 mm | Axial displacement |
| E | 177.50 mm | Raceway diameter outer ring |
| F | 121.50 mm | Raceway diameter inner ring |
| D1 min | 169.62 mm | Minimum rib diameter outer ring |
| d1 | 132.00 mm | Maximum rib diameter inner ring |
Temperature range
| Tmin | -30.00 °C | Operating temperature min. |
| Tmax | 150.00 °C | Operating temperature max. |
Additional information
| HJ2319-E | L-washer |
Your current product variant
| Design | E | Increased Capacity Design |
| Cage | M1 | Two Piece Brass Cage Roller Guided |
| Radial internal clearance | CN | Group N (CN) |
| Tolerance class | PN | Normal (PN) |
