DIMENSIONS
|
d |
80 mm | Bore diameter |
|
D |
170 mm | Outside diameter |
|
B |
39 mm | Width |
|
d1 |
≈108 mm | Shoulder diameter |
|
D2 |
≈146.9 mm | Recess diameter |
|
r1,2 |
min.2.1 mm | Chamfer dimension |
ABUTMENT DIMENSIONS
|
da |
min.92 mm | Diameter of shaft abutment |
|
Da |
max.158 mm | Diameter of housing abutment |
|
ra |
max.2 mm | Radius of shaft or housing fillet |
CALCULATION DATA
| Basic dynamic load rating |
C |
130 kN |
| Basic static load rating |
C0 |
86.5 kN |
| Fatigue load limit |
Pu |
3.25 kN |
| Reference speed |
|
8 500 r/min |
| Limiting speed |
|
5 300 r/min |
| Minimum load factor |
kr |
0.03 |
| Calculation factor |
f0 |
13.3 |
MASS
| Mass bearing | 3.63 kg |
TOLERANCE CLASS
| Dimensional tolerances | P6 |
| Radial run-out | Normal |
