Categories: Spherical Roller Bearing
● d - 90 mm
● D - 160 mm
● B - 40 mm
● C - 40 mm
● r min. - 2 mm
● da min. - 100 mm
● da max - 108 mm
● Da min - 142 mm
● Da max. - 150 mm
● ra max. - 2 mm
● Weight - 3,3 Kg
● Basic dynamic load rating (C) - 289 kN
● Basic static load rating (C0) - 395 kN
● (Grease) Lubrication Speed - 2800 r/min
● (Oil) Lubrication Speed - 3600 r/min
● Calculation factor (e) - 0,24
● Calculation factor (Y0) - 2,8
● Calculation factor (Y2) - 4,3
● Calculation factor (Y3) - 2,9
